Fibre Channel Adapter Installation for HP-UXLED InterpretationChapter 112LED InterpretationObtaining Card Information after InstallationExample of Card information after Installation# fcmsutil /dev/fcd9Vendor ID is = 0x001077Device ID is = 0x002422PCI Sub-system Vendor ID is = 0x00103cPCI Sub-system ID is = 0x0012d7PCI Mode = PCI-X 133 MHzISP Code version = 4.0.85ISP Chip version = 3Topology = PTTOPT_FABRICLink Speed = 4GbLocal N_Port_id is = 0x030000Previous N_Port_id is = NoneN_Port Node World Wide Name = 0x50060b00003b20f1N_Port Port World Wide Name = 0x50060b00003b20f0Switch Port World Wide Name = 0x200000051e352af4Switch Node World Wide Name = 0x100000051e352af4Driver state = ONLINEHardware Path is = 0/0/2/1/0Maximum Frame Size = 2048Table 1-3 AB379B LED Interpretation TableHBA StateYellowLED(4 Gbps)GreenLED(2 Gbps)AmberLED(1 Gbps)CommentsPower OFF OFF OFF OFF Card doesn’t have powerPower ON ON ON ON Card powered on and not initializedPower ON 1 Flash/s 1 Flash/s 1 Flash/s After firmware initialization AWAITING LINK-UPAll flashing at the same timeFirmwareFault2 Flash/s 2 Flash/s 2 Flash/s All three LEDs flash in continuous sequence1 Gbps LinkUP/ACTOFF OFF ON5 Flash/sONLINEIO Activity2 Gbps LinkUP/ACTOFF ON5 Flash/sOFF ONLINEIO Activity4 Gbps LinkUP/ACTON5 Flash/sOFF OFF ONLINEIO Activity
