Fibre Channel Adapter Installation for HP-UXVerifying ConnectivityChapter 114Verifying ConnectivityOnce your HP Fibre Channel Mass Storage software and hardware is installed and running, follow thesesteps to verify connectivity:Step 1. Check the state of all Fibre Channel hardware and interfaces. Enter the ioscan command andverify that the Hardware State and the HW-Interface State are CLAIMED.If the Fibre Channel device file has not been created, enter the following commands:# insf -e# ioscan -fStep 2. Verify that all devices you attached to the Fibre Channel adapter are listed in the ioscan output.For example, if you have a direct attach Fibre Channel device attached to the system, the ioscanoutput may look like the following:0/5/0.8.0.255.0.1.0 sdisk CLAIMED DEVICE DGC C3400WDR5The example above is the hardware path of LUN0 of a directly attached Fibre Channel MassStorage device with Loop ID of 1.If all attached devices are listed and appear as CLAIMED, HP Fibre Channel Mass Storage installation isverified.If all attached devices are not listed or appear as UNCLAIMED, see the Troubleshooting and Maintenancechapter of the HP Fibre Channel Adapters Support Guide.Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)Example 1-1, Example 1-2 and Example 1-3 illustrate the Fibre Channel hardware path format:Example 1-1 Hardware Path for a Public Loop DeviceExample 1-2 Hardware Path for a Direct Fabric Attach DeviceExample 1-3 Hardware Path for a Private Loop DeviceAdapter Area Port Bus Target LUNDomain0/1/2/0.1.19.255.15.4.0Adapter Area Port Bus Target LUNDomain0/1/2/0.1.19.255.0.0.0Adapter Area Port Bus Target LUNDomain0/1/2/0.8.0.255.0.1.0
