Fibre Channel Adapter Installation for HP-UXInterpreting Lunpath Hardware Paths (HP-UX 11i v3)Chapter 119The controller, target, and lun values are extracted from the LUN id as shown in the table:To convert a lunpath hardware path to a legacy hardware path, use the scsimgr get_info command on thetarget’s hardware path to display the port_id, which contains the domain, area, and port values. Extract thecontroller, target, and lun values from the LUN id.The following example uses lunpath hardware path 0/2/1/0.0x500805f300083899.0x4011000000000000:# scsimgr get_info -H 0/2/1/0.0x500805f300083899STATUS INFORMATION FOR TARGET PATH : 0/2/1/0.0x500805f300083899Generic Status InformationSCSI services internal state = IDLEPort id = 0x10700Protocol = fibre_channelProtocol revision = 4.3Port name = 0x500805f300083899Node name = 0x500805f300083890LUN paths registered (active/inactive) = 12A port_id of 0x10700 yields a domain value of 1, an area value of 7, and a port value of 0.The LUN address of 0x4011000000000000, which represents LUN id 0x11, yields a controller value of 0, atarget value of 2 and a lun value of 1.The resultant legacy hardware path is 0/2/1/0.1.7.0.0.2.1.To confirm this mapping, use the ioscan –m hwpath command, as follows:# ioscan -m hwpath -H 0/2/1/0.0x500805f300083899.0x4011000000000000Lun H/W Path Lunpath H/W Path Legacy H/W Path=============================================================================64000/0xfa00/0x40/2/1/0.0x500805f300083899.0x4011000000000000 0/2/1/0.1.7.0.0.2.1Table 1-8Controller(7 bits)Target(4 bits)LUN(3 bits)0-63 0-15 0-7
