AB379B Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB379B Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
- AB379B Technical Specifications
- FCC Statement (For U.S.A.)
- Canada
- EMI (Australia and New Zealand)
- VCCI (Japan) (PCI Card Only)
- EMI Statement (European Community)
- Laser Safety Statements
- AB379B Declaration of Conformity
Chapter 2212 Fibre Channel Adapter Installation forOpenVMSThis chapter contains installation prerequisites, guidelines, and procedures for the AB379B host bus adapter.This chapter addresses the following topics:“Prerequisites” on page 21“Installing Driver Software” on page 22“Installing Adapter Hardware” on page 22“Attaching the Adapter to Other Fibre Channel Devices” on page 24“Verifying the Fibre Channel Adapter Installation” on page 24“Additional Configuration Information” on page 26“LED Interpretation” on page 26Thank you for purchasing HP I/O CardsIf you are installing an HP I/O card as an add-in device, please review this document before attemptinginstallation.If this card was factory installed in your server, see “Verifying the Fibre Channel Adapter Installation” onpage 24.HP welcomes your input. Please email us at:netinfo_feedback@cup.hp.comwith comments or suggestions on HP I/O Cards or related documentation.All product documentation, including a comprehensive Support Guide, Installation Guide, Release Notes,Support Matrix are available online at: http://docs.hp.com1. Within the “Internet & Networking” category select “I/O Cards and Networking Software”2. Select “Fibre Channel”3. Click on the Fibre Channel documentation product.PrerequisitesBefore installing the adapter, follow these steps:Step 1. Verify compliance with supported sonfigurations using the HP Fibre Channel Host Bus AdapterSupport Matrix at:http://docs.hp.com/en/netcom.html#Fibre%20ChannelStep 2. Determine if the adapter is a Customer Replaceable Unit (CRU) using the HP Fibre Channel HostBus Adapter Support Matrix. If the adapter is not a CRU, contact your HP representative forinstallation assistance.Field Replaceable Units (FRUs) must be installed or replaced by qualified Hewlett-Packard servicerepresentatives only. CRUs can be installed or replaced by customers or qualified Hewlett-Packardservice representatives.Step 3. Make sure that you have everything that you need to install the adapter.• Verify that you have the following items:— Grounding wrist strap— Fibre Channel driver software media (included with the OS or application CD)— Fibre Channel host bus adapter with an optical port protector attached (not included withall adapters)• Verify that you have the following cabling items:— Fiber optic cable terminated with a duplex LC connector. Cable must be 50 or 62.5 micronmultimode cable.— Cable map (optional)
