AB379B Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB379B Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
- AB379B Technical Specifications
- FCC Statement (For U.S.A.)
- Canada
- EMI (Australia and New Zealand)
- VCCI (Japan) (PCI Card Only)
- EMI Statement (European Community)
- Laser Safety Statements
- AB379B Declaration of Conformity
Fibre Channel Adapter Installation for OpenVMSAdditional Configuration InformationChapter 226SDA> FC SHOW STDTSYS$PGQDRIVER - QLogic ISP24xx - FGA0 - SPDT 8272B100 - STDTs-------------------------------------------------------------| STDT Cred Port FP NP Appr | Act Cmd Cnf Cls | QF SeqSTDT FC-LA Port Name LID PortID | Stat I/Os I/Os I/Os I/Os I/Os | Sus Sus Pnd Pau | Seen TMOs-------- ----- ------------------- --- ------ + ---- ---- ---- ---- ---- ---- + --- --- --- --- + ---- ----82B84BC0 00010 5000.1FE1.5001.A3EC 091 013200 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000082B88E80 00015 5000.1FE1.0015.2D08 097 020800 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000082B7CE00 00006 5000.1FE1.0015.2C58 087 011500 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000082B8AD00 00016 5000.1FE1.5001.40D8 098 011A00 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000082B7D5C0 00007 5000.1FE1.5004.E148 08C 030800 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000ESDA>Additional Configuration InformationNOTE OpenVMS only supports Fibre Channel connection via a Fibre Channel switch. Arbitrated loopand point-to-point topologies are not supported.Review the Guidelines for OpenVMS Cluster Configurations located at:http://www.hp.com/go/openvms/docfor additional information about configuring and booting Fibre Channel devices on OpenVMS.LED InterpretationTable 2-2 AB379B LED Interpretation TableHBA StateYellowLED(4 Gbps)GreenLED(2 Gbps)AmberLED(1 Gbps)CommentsPower OFF OFF OFF OFF Card doesn’t have powerPower ON ON ON ON Card powered on and not initializedPower ON 1 Flash/s 1 Flash/s 1 Flash/s After firmware initialization AWAITING LINK-UPAll flashing at the same timeFirmwareFault2 Flash/s 2 Flash/s 2 Flash/s All three LEDs flash in continuous sequence1 Gbps LinkUP/ACTOFF OFF ON5 Flash/sONLINEIO Activity2 Gbps LinkUP/ACTOFF ON5 Flash/sOFF ONLINEIO Activity4 Gbps LinkUP/ACTON5 Flash/sOFF OFF ONLINEIO Activity
