AB379B Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB379B Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
- AB379B Technical Specifications
- FCC Statement (For U.S.A.)
- Canada
- EMI (Australia and New Zealand)
- VCCI (Japan) (PCI Card Only)
- EMI Statement (European Community)
- Laser Safety Statements
- AB379B Declaration of Conformity
Appendix A27A Technical Specifications and RegulatoryInformationAB379B Technical SpecificationsTable A-1Performance CharacteristicsLocal bus mode and speed PCI-X 266MHz, PCI-X 133MHz, PCI-X 66MHz, PCI 66MHz, PCI 33MHzConnectivity Dual port Fibre Channel, multi-mode short-wave optical linkLink Speed 4 Gbps / 2 Gbps / 1 GbpsLink Distance 4Gbps : 150m; 2Gbps : 300m; 1Gbps : 500mOver 50/125um multi-mode fiber optic cableConnector Two LC Duplex ConnectorsBus Slot 3.3V only, 64-bit PCI-X 266MHz, PCI-X 133MHz, PCI-X 66MHz, PCIPhysicalLength 168 mm (6.61 inches)Width 64.5 mm (2.54 inches)Height 9.8 mm (0.39 inches)Weight 104 g (3.7 Oz)Electrical 6.5 watts (nominal); 8.0watts (max)Standards Complies with ANSI standards (ANSI X3T11) for standard Fibre Channel,PCI Local Bus specification Rev 2.3, PCI-X protocol addendum rev 2.0a, andPCI-X Electrical/Mechanical spec 2.0aEnvironmentalTemperature +5 to +40 degrees C (+41 to +104 F) operating-40 to +70 degrees C (-40 to +177 F) non operatingRelative Humidity 5% to 90% @ 65 degrees C (149 degrees F) non-condensing, non-operating20% to 80% @ 40 degrees C (104 degrees F) non-condensing, operatingAltitude 4.5 km (15,000 ft)ElectromagneticUSA FCC Class AEurope CISPR-22 Class AGermany FTZ-1046 (VDE Level B)Japan VCCI Class ILaser Safety Class 1
