AB379B Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB379B Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
- AB379B Technical Specifications
- FCC Statement (For U.S.A.)
- Canada
- EMI (Australia and New Zealand)
- VCCI (Japan) (PCI Card Only)
- EMI Statement (European Community)
- Laser Safety Statements
- AB379B Declaration of Conformity
Chapter 151 Fibre Channel Adapter Installation forHP-UXThis chapter contains installation prerequisites, guidelines, and procedures for the AB379B host bus adapter.This chapter addresses the following topics:“Prerequisites” on page 5“Important Patches and Updates” on page 6“Installing Driver Software” on page 6“Installing Adapter Hardware” on page 8“Attaching the Adapter to Other Fibre Channel Devices” on page 10“Verifying the Fibre Channel Adapter Installation” on page 11“LED Interpretation” on page 12“Obtaining Card Information after Installation” on page 12“Verifying Connectivity” on page 14“Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)” on page 14“Interpreting Lunpath Hardware Paths (HP-UX 11i v3)” on page 17Thank you for purchasing HP I/O CardsIf you are installing an HP I/O card as an add-in device, please review this document before attemptinginstallation.If this card was factory installed in your server, see “Verifying the Fibre Channel Adapter Installation” onpage 11.HP welcomes your input. Please email us at:netinfo_feedback@cup.hp.comwith comments or suggestions on HP I/O Cards or related documentation.All product documentation, including a comprehensive Support Guide, Installation Guide, Release Notes,Support Matrix are available online at: http://docs.hp.com1. Within the “Internet & Networking” category select “I/O Cards and Networking Software”2. Select “Fibre Channel”3. Click on the Fibre Channel documentation product.PrerequisitesBefore installing the adapter, follow these steps:Step 1. Verify compliance with supported sonfigurations using the HP Fibre Channel Host Bus AdapterSupport Matrix at:http://docs.hp.com/en/netcom.html#Fibre%20ChannelStep 2. Determine if the adapter is a Customer Replaceable Unit (CRU) using the HP Fibre Channel HostBus Adapter Support Matrix. If the adapter is not a CRU, contact your HP representative forinstallation assistance.Field Replaceable Units (FRUs) must be installed or replaced by qualified Hewlett-Packard servicerepresentatives only. CRUs can be installed or replaced by customers or qualified Hewlett-Packardservice representatives.Step 3. Check the following conditions:• To verify that the /usr/bin, /usr/sbin, and /sbin directories are in the PATH, enter thefollowing command:echo $PATH
