AB379B Fibre Channel Mass Storage Adapter Installation Guide, February 2007
Table Of Contents
- AB379B Fibre Channel Mass Storage Adapter Installation Guide
- 1 Fibre Channel Adapter Installation for HP-UX
- Prerequisites
- Important Patches and Updates
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- LED Interpretation
- Obtaining Card Information after Installation
- Verifying Connectivity
- Interpreting Legacy Hardware Paths (HP-UX 11i v1 and 11i v2)
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
- Components of Lunpath Hardware Paths
- Fibre Channel
- 2 Fibre Channel Adapter Installation for OpenVMS
- Prerequisites
- Installing Driver Software
- Installing Adapter Hardware
- Attaching the Adapter to Other Fibre Channel Devices
- Verifying the Fibre Channel Adapter Installation
- Additional Configuration Information
- LED Interpretation
- A Technical Specifications and Regulatory Information
- AB379B Technical Specifications
- FCC Statement (For U.S.A.)
- Canada
- EMI (Australia and New Zealand)
- VCCI (Japan) (PCI Card Only)
- EMI Statement (European Community)
- Laser Safety Statements
- AB379B Declaration of Conformity
Fibre Channel Adapter Installation for HP-UXInstalling Adapter HardwareChapter 18Installing Adapter HardwareThe Online Addition and Replacement feature, OLAR for HP-UX 11i v1, or OL* for HP-UX 11i v2 and laterHP-UX releases, enables PCI host bus adapters to be added or replaced without shutting down and rebootingthe system, and without adversely affecting other system components. The system hardware uses slot-specificpower control, combined with HP-UX operating system support, to enable these features.Confirm whether OLAR or OL* are supported on the system in wich you plan to install a Fibre Channeladapter. See the HP Fibre Channel Host Bus Adapter Support Matrix, at:http://docs.hp.com/en/netcom.html#Fibre%20ChannelFor detailed instructions on using OLAR on HP-UX 11i v1, see Chapter 2 of Configuring HP-UX forPeripherals, which can be accessed at:http://docs.hp.com/en/hpux11i.htmlFor detailed instructions on using OL* on HP-UX 11i v2 and later HP-UX releases, see the Interface CardOL* Support Guide at:http://www.docs.hp.com/en/netsys.html#System%20AdministrationIMPORTANT Superdome systems are not intended to be maintained by customers. HP recommends thatSuperdome systems only be opened by a qualified HP service engineer. Failure to observe thisrecommendation can invalidate any support agreement or warranty to which you may beentitled.Installing the Fibre Channel AdapterCAUTION Observe all ESD safety precautions before attempting this procedure. Failure to follow ESDsafety precautions could result in damage to equipment.NOTE The optical port protector is used only to protect the adapter port when it is not in use. Do notuse the protector as a diagnostic tool.Install OnlineDiag, which is available at:http://www.software.hp.comOnlineDiag is also available from the HP Support PLUS CD for HP/9000 systems or the IPFxxxx CD forItanium systems. Installation instructions are available at:http://docs.hp.com/hpux/onlinedocs/diag/st/st_inst.htmInstall all driver software and dependent patches before you install the adapter. For more information, seeFibrChanl-01 (fcd) Fibre Channel Mass Storage Driver Release Notes available at:http://docs.hp.com/en/netcom.html#Fibre%20ChannelNOTE See the system documentation for information about how to safely shut down your system andobtain access to expansion slots.To install the Fibre Channel adapter, follow these steps:
- A Technical Specifications and Regulatory Information
- Interpreting Lunpath Hardware Paths (HP-UX 11i v3)
