Virtual Connect server profiles 203
The screen can be edited only by users with server role permissions, but it is viewable by all authorized users.
The following table describes the fields within the Edit Server Profile screen.
Column name Description
Profile
Profile Name
Descriptive name for the server profile. Do not use spaces.
Network Access Group
Associates a network access group to the profile
Status
Status of the server profile
Serial Number
The serial number assigned to this profile from the serial number pool selected
