Trap name Trap data Description
vcModPortBpduLoopDetected
port identification
loop status
A network loop condition is detected on this port. If the
loop condition is detected on a Flex10 port, the trap data
indicates the physical port associated with the Flex10
port.
If multiple Flex10 ports on a physical port detect a loop
condition, a separate trap is sent for each occurrence of
the loop condition.
vcModPortBpduLoopCleared
port identification
loop status
A network loop condition is cleared on this port. The trap
data indicates the physical port associated with a Flex10
port.
For Flex10 ports, this trap is sent only after all Flex10
ports on a physical port are cleared from a loop
condition.
vcModPortProtectionConditio
nDetected
Port index to the
ifTable (ifIndex)
Port index to the
vcModulePortTable
Port protection status
A port protection condition is detected on this port. If the
new port protection status is a value other than OK, the
port may be disabled to protect the VC module from
further service degradation. Administrative action is
required to recover the port from this condition.
vcModPortProtectionConditio
nCleared
Port index to the
ifTable (ifIndex)
Port index to the
vcModulePortTable
Port protection status
The port is recovered from port protection condition to
normal operational state.
VC Domain MIB traps
The Virtual Connect vc-domain-mib.mib MIB provides visibility into the various components of a Virtual
Connect Domain.
VC Domain Managed Status Changed traps
This section describes the *ManagedStatus, *Cause, *RootCause, and *ReasonCode OIDs found in each
*ManagedStatusChanged traps in the VC Domain MIB.
The ManagedStatus enumerations (vcDomainManagedStatus, vcEnclosureManagedStatus, and so on) for
all managed status changed objects (vcDomainManagedStatusChanged,
cEnclosureManagedStatusChanged, and so on) are described in the following table.
Managed status Description
unknown
Indicates the condition of the component could not be determined
normal
Indicates the component is fully functional
warning
Indicates a component threshold has been reached or error condition is imminent
minor
Indicates an error condition exists that has little or no component impact
major
Indicates an error condition exists that significantly impairs the component
critical
Indicates an error condition exists where the component no longer provides service
disabled
Indicates the component is disabled and non-functioning
info
Indicates a non-service affecting condition exists such as initializing components and
system login/logout
