HP Virtual Connect Manager 18
Menu items
The following table lists the items available from the pull-down menu at the top of the screen.
Menu item Links to
Define
Ethernet Network
Define Ethernet Network screen (on page 114)
SAN Fabric
Define SAN Fabric screen (on page 149)
Shared Uplink Set
Define Shared Uplink Set screen (on page 124)
Network Access Group
Define Network Access Group screen (on page 89)
Server Profile
Define Server Profile screen (on page 178)
Configure
Domain Settings
Domain Settings (Configuration) screen (on page 22)
Ethernet Network Settings
Ethernet Settings (MAC Addresses) screen (on page 173)
Quality of Service (QoS)
Quality of Service screen (on page 102)
IGMP Settings
IGMP Settings (IGMP Configuration) screen (on page 109)
Fibre Channel Settings
Fibre Channel Settings (WWN Settings) screen (on page 175)
Serial Number Settings
Serial Number Settings screen (on page 176)
Local User Accounts
Local Users screen (on page 66)
Certificate Administration
SSL Certificate Administration (Certificate Info) screen (on page 51)
Tools
Hardware Overview
Enclosures View ("Enclosures View screen" on page 62)
Domain Setup Wizard
Welcome screen for the Domain Setup Wizard
Network Setup Wizard
Welcome screen for the Network Setup Wizard
Fibre Channel Setup Wizard
Welcome screen for the Fibre Channel Setup Wizard
Server Profile Setup Wizard
Welcome screen for the Server Profile Setup Wizard
Throughput Statistics
Throughput Statistics screen (on page 226)
Backup/Restore Domain
Configuration
Domain Settings (Backup/Restore) screen (on page 27)
System Log
System Log (System Log) screen (on page 47)
Export Support Information
Export Support Information (on page 272)
Reset Virtual Connect Manager
Reset Virtual Connect Manager (on page 273)
Help
Table of contents
VC Manager help file table of contents
Index
VC Manager help file index
For This Page
Help topic specific to the current page
Virtual Connect Documentation on
hp.com
The Virtual Connect Documentation page on the HP website
(http://www.hp.com/go/bladesystem/documentation)
About HP Virtual Connect Manager
Specific information about this Virtual Connect domain
Activity indicator
The GUI displays current activity in a pane attached to the bottom of the browser window, including a
progress bar that displays the activity status graphically. The activity pane includes four controls:
• Up and down arrow buttons scroll through the recent activity history during the current GUI session.
• A collapse button temporarily hides the activity pane until the next activity update.
