Virtual Connect domains 22
Domain Settings (Configuration) screen
Use this screen to change the domain name, delete a domain, and configure a customized login screen
message. To access this screen, click Configuration in the left navigation tree, or select Domain Settings from
the Configure menu. Only users with domain role permission can make changes on this screen.
The following table describes the available actions in the Domain Settings (Configuration) screen. Clicking
another link in the pull-down menu or left navigation tree causes current edits that have not been applied to
be lost.
Task Action
Change the domain name
Enter the revised domain name, and then click Apply.
Display single-dense server bays
Click the checkbox next to the appropriate selection. Available if
double-dense compatibility is selected during import.
Delete a domain
Verify that the correct domain name is displayed, and then click
Delete Domain. See "Deleting a domain (on page 22)."
Add banner text to the login screen
Select the Enable Display of Banner on User Login checkbox, enter a
customized message in the Banner Text field (up to 1500 printable
ASCII characters in length), and then click Apply. Users are required
to acknowledge the banner text before they can log in.
Clear changes and remain on this screen
Click Revert.
Save changes
Click Apply.
Deleting a domain
