HP Virtual Connect for c-Class BladeSystem Version 4.01 User Guide

Virtual Connect domains 43
Task Action
Add an SNMP trap destination
("Adding an SNMP trap
destination" on page 43)
Click Add below the destination table, or right-click on the header row of
the destination table, and then select Add Destination.
Edit an SNMP trap destination
Click Edit in the Action column, or right-click on the trap destination row,
and then select Edit Destination.
Delete an SNMP trap destination
Click Delete in the Action column, or right-click on the trap destination
row, and then select Delete Destination.
Save changes
Click Apply.
Adding an SNMP trap destination
To add an SNMP trap destination, right-click the header row of the SNMP Trap Destination table, or click
Add at the bottom of the SNMP Trap Destination table.
You can configure up to five VC-Enet and five VC-FC SNMP trap destinations. To add an SNMP trap
destination:
1. Enter a unique name for the new trap being added. No spaces are allowed.
2. Enter the IPv4 address or DNS name for the trap destination. DNS is not supported for VC-FC modules.
3. Select the Trap Format: SNMPv1 or SNMPv2. SNMPv2 is not supported for VC-FC modules.
4. Enter the SNMP trap community string for the specified trap. The default is "public."
For VC-Enet modules, the maximum trap community string length is 39.
For VC-FC modules, the maximum trap community string length is 24.
5. Click OK to save the information and return to the main SNMP configuration screen, or continue and
select trap categories or trap severities.
