Virtual Connect users and roles 75
Field Description
Add/Remove Secondary
Server
Select to add or remove a secondary RADIUS server.
To add a secondary server, select the Add/Remove Secondary Server checkbox to display the Secondary
Server Parameters, complete the fields as described in the table above, and then click Apply. The secondary
server is queried only if the primary server is down or the request to the primary server times out.
To remove a secondary server, clear the Add/Remove Secondary Server checkbox, and then click Apply.
Required RADIUS server settings
The following RADIUS server settings must be configured on VC to enable RADIUS-based authentication:
• Enable or disable flag
• Server Address
• Server SSL port—the default (well-known) value for RADIUS authentication is 1812.
• Server Timeout—the time in seconds by which a server response needs to be received before any retry
for a new request is made. The valid range of values is from 1 to 65535 seconds.
• Server Key—this is a plaintext key that must be configured both on VC and on the server. Both keys
should match. The length of the secret key can vary from 1 to 128 characters.
IMPORTANT: If the same username is used in multiple groups, the HP-VC-Groups attribute must
be the last attribute that is defined.
Setting up a RADIUS server
The following procedure provides an example of setting up a RADIUS server on an external host running
Linux:
1. Download and install the latest version of the open-source FreeRadius server from the FreeRadius
website (http://freeradius.org/download.html).
2. Add the user entry to the file freeradius-server-2.1.9/raddb/users:
<username> Cleartext-Password := "<password>"
Service-Type = Login-User,
HP-VC-groups = <groupname>
o "Cleartext-Password" is used to define the password.
o "Service-Type" must be always set to "Login-User".
o "HP-VC-Groups" is a HP-specific attribute used to define the group(s) that a user belongs to.
Be sure that the username does not conflict with any of the local user accounts configured on the RADIUS
server host. Otherwise, the RADIUS server will use UNIX-based authentication to look up the local
/etc/passwd file. The server will not look up freeradius-server-2.1.9/raddb/users.
3. Add the client entry to the file freeradius-server-2.1.9/raddb/clients.conf:
client <hostname/IP> {
ipaddr = <IP address>
secret = <plain-text secret>
require_message_authenticator = no
