Virtual Connect networks 135
Field Description
Shared Uplink Set
Displays the status, UID, and name of the shared uplink set
Has FCoE
Indicates whether the shared uplink set contains an FCoE network
Port Status
Shows the link status, link speed, and connectivity of the port. If the port is unlinked and
no connectivity exists, the cause is displayed. For more information about possible
causes, see "Port status conditions (on page 264)."
Connector Type
The type of connector on the port; for example, SFP-SX
Uplink Port
Enclosure, bay, and port number of the external uplink
Action
Perform edit, delete, and copy operations
The following table describes the available actions in the Shared Uplink Sets (External Connections) screen.
Clicking another link in the pull-down menu or left navigation tree causes current edits that have not been
applied to be lost.
Task Action
Add a shared uplink set
Click Add below the table, or right-click on the header row to display a
menu, and then select Add.
Edit a shared uplink set
Click the Edit link in the Action column, or left-click to select an uplink set,
right-click to display a menu, and then select Edit.
Delete a shared uplink set
Click the Delete link in the Action column, or left-click to select an uplink
set, right-click to display a menu, and then select Delete.
Copy a shared uplink set
Click the Copy link in the Action column, or left-click to select an uplink set,
right-click to display a menu, and then select Copy. For more information,
see "Copy Shared Uplink Set screen (on page 135)."
Copy Shared Uplink Set screen
To access this screen:
• Click the Copy link for a shared uplink set on the Shared Uplink Sets (External Connections) screen (on
page 134).
• Select a shared uplink set on the Shared Uplink Sets (External Connections) screen (on page 134),
right-click to display a menu, and then select Copy.
