Virtual Connect modules 238
Ethernet Bay Summary (IGMP Multicast Groups) screen
This screen shows the IGMP multicast groups that are active on ports of this VC-Enet module. The multicast
group IP address, the port, and its MAC address are shown in the table.
The following table describes the columns within the IGMP Multicast Groups table.
Column Description
Port
Label of the port that is participating in the multicast group
Flex-10 downlinks ports are displayed as dx:vx, for example, d1:v1
IP Address
IP address of the multicast group
MAC Address
Multicast group MAC address
