Virtual Connect domains 40
The following is an example of a FC fabric RootCause string:
1 of 2 uplink ports are abnormal on BackupSAN fabric
The FC fabric managed status ReasonCodes are provided in the following table.
FC fabric reason code Description
vcFabricOk
The fabric is functioning normally.
vcFabricNoPortsConfigured
The fabric does not have any uplink port configured.
vcFabricSomePortsAbnormal
Some uplink ports for the fabric are in an abnormal condition.
vcFabricAllPortsAbnormal
All uplink ports for the fabric are in an abnormal condition.
vcFabricWwnMismatch
A WWN mismatch condition has been detected.
vcFabricUnknown
The condition of the fabric is unknown.
vcEnetNetworkManagedStatusChanged
The following is an example of a Ethernet network Cause string:
Network BLUE has failed
The following is an example of a Ethernet network RootCause string:
Port enc0:iobay5:X3 is unlinked; Port enc0:iobay5:X4 is incompatible
The Ethernet network managed status ReasonCodes are provided in the following table.
Ethernet network reason code Description
vcNetworkOk
The network is functioning normally.
vcNetworkUnknown
The condition of the network is unknown.
vcNetworkDisabled
The network is disabled.
vcNetworkAbnormal
The condition of the network is abnormal.
vcNetworkFailed
The network is in a failed condition.
vcNetworkDegraded
The network is in a degraded condition.
vcNetworkNoPortsAssignedToPrivateNetwor
k
No ports have been assigned to the private network.
vcProfileManagedStatusChanged
The following is an example of a profile Cause string:
3 TCServer profile connections for server in bay enc0:devbay3 are not mapped
The following is an example of a profile RootCause string:
The TelecomServer profile is assigned to an abnormal server in bay
enc0:devbay1
The profile managed status ReasonCodes are provided in the following table.
Profile reason code Description
vcProfileOk
The profile is normal.
vcProfileServerAbnormal
The server the profile is assigned to is abnormal.
vcProfileAllConnectionsFailed
All connections in the profile have failed.
vcProfileSomeConnectionsUnmapped
One or more connections in the profile are not mapped to a
physical port.
vcProfileAllConnectionsAbnormal
All connections in profile are abnormal.
vcProfileSomeConnectionsAbnormal
Some connections in the profile are abnormal.
