Virtual Connect domains 53
Row Description
Valid until
The date and time when this certificate becomes invalid
Serial Number
Serial number of the certificate. This serial number is unique per Certificate
Authority that issued it.
Version
Version of the certificate
MD5 Fingerprint
Unique fingerprint of the certificate, calculated using cryptographic hash
function Message-Digest algorithm 5 (MD5). This fingerprint can be used to
further verify that the correct certificate is being used.
SHA1 Fingerprint
Unique fingerprint of the certificate, calculated using cryptographic hash
function Secure Hash Algorithm 1 (SHA1). This fingerprint can be used to further
verify that the correct certificate is being used.
Key Length
Key length of the certificate.
Required Information
Country (C)
The two character country code that identifies the country where the VC domain
is located
State or Province (ST)
The state or province in which the VC domain is located
City or Locality
The city or locality in which the VC domain is located
Organization Name (O)
The company that owns the VC domain
Optional Data
Alternative Name
Alternative names for the VC domain that the certificate also covers
Contact Person
The person responsible for the VC domain
Email Address
The email address of the person responsible for the VC domain
Organizational Unit
The unit within the company or organization that owns the VC domain
Surname
The surname of the person responsible for the VC domain
Given Name
The given name of the person responsible for the VC domain
Initials
The initials of the person responsible for the VC domain
DN Qualifier
The distinguished name qualifier of the VC domain
Unstructured Name
This field is for specifying the name of the subject of the certificate in an
unstructured ASCII string. The interpretation of the name is specified by the
certificate issuer.
