HP Virtual Connect for c-Class BladeSystem Version 4.01 User Guide

Virtual Connect networks 114
4.
(Optional) Enter a label for the set.
5. Drag and drop multicast filters that should be members of the filter set from the Excluded filter set field
to the Included filter set field.
6. Click Apply.
To edit a multicast filter set:
1. Click on the set to edit.
2. Make any changes.
3. Click Apply.
A multicast filter can be removed from a multicast filter set, or a filter rule can be deleted from a multicast filter
while it is associated with a profile Ethernet connections. In this case, for all existing IGMP groups the server
port is a member of, the port is deleted from the group when the idle timer expires.
To delete a multicast filter set, highlight the set, and then click Delete.
Define Ethernet Network screen
The Define Ethernet Network screen is accessible to all users with network role permissions from the Define
a Network link on the Virtual Connect Manager homepage or the Define pull-down menu.
The following table describes the fields within the Define Ethernet Network screen.
Field name Description
Network
Network Name
Name of the network
Color
A network can have a user-defined color to group and identify the network
within VCM.
