The following tables describe the rows within the FC Port Detailed Statistics screen.
Port Information Description
Port Number
The uplink port number
Connector Type
Type of port connector, for example, SFP-SX
Interconnect Bay
Number of the interconnect bay where the port is located
WWN
Factory assigned WWPN for this uplink port
SAN Fabric
Name of the SAN Fabric connected to this port
Connector Status
Status of the uplink port
Connected To
WWN of the principal FC switch to which the VC-FC uplink port is
connected
Port Speed Setting
Speed setting of the uplink port
Port Statistics Description
fcRxFrameRate
Average receive frame rate (f/s) for the sample period
fcTxFrameRate
Average transmit frame rate (f/s) for the sample period
fcRxByteRate
Average receive byte rate (B/s) for the sample period
fcTxByteRate
Average transmit byte rate (B/s) for the sample period
fcTotalRxFrames
Number of frames received
fcTotalTxFrames
Number of frames transmitted
fcAddressErrors
Number of frame address ID errors
fcClass2RxFrames
Number of Class 2 frames received
fcClass2TxFrames
Number of Class 2 frames transmitted
fcClass3RxFrames
Number of Class 3 frames received
fcClass3TxFrames
Number of Class 3 frames transmitted
fcClass3Discards
Number of discarded Class 3 frames
fcInvalidCRC
Number of frames received with invalid CRC
fcFramesTooLong
Number of invalid long frames received
fcFramesTruncated
Number of invalid short frames received
fcFRJTFrames
Number of Class 2 FRJT frames received
fcFBSYFrames
Number of Class 2 FBSY frames received
fcTotalRxBytes
Total number of bytes received
fcTotalTxBytes
Total number of bytes transmitted
fcBBCreditFrameFailures
Number of Link Resets due to frames lost during credit recovery
fcBBCreditRRDYFailures
Number of Link Resets due to multiple R_RDY during credit recovery
period
fcLinkFailures
Number of link failures
fcRxLinkResets
Number of Link Resets received
fcTxLinkResets
Number of Link Resets transmitted
fcNumberLinkResets
Total number of Link Resets
fcLossOfSynchronization
Number of Loss of Sync errors
fcRxOfflineSequences
Number of Offline Sequences received
fcTxOfflineSequences
Number of Offline Sequences transmitted
fcNumberOfflineSequences
Total number of Offline Sequences
fcPrimitiveSeqProtocolErrors
Number of Primitive Sequence protocol errors
