Virtual Connect domains 39
Enclosure reason code Description
vcEnclosureUnknown
The condition of the enclosure cannot be determined, or the state of
servers or modules is unknown.
vcModuleManagedStatusChanged
The following is an example of a module Cause string:
Port enc0:iobay5:d3:v1 loop detected and automatically disabled
The following is an example of a module RootCause string:
Port enc0:iobay5:d3:v1 loop detected and automatically disabled
The module managed status ReasonCodes are provided in the following table.
Module reason code Description
vcEnetmoduleOk
The Ethernet module is functioning normally.
vcEnetmoduleEnclosureDown
The module is unable to communicate with the enclosure/OA.
vcEnetmoduleModuleMissing
A configured module has been removed.
vcEnetmodulePortprotect
A condition has been detected on the port causing port protection to
be activated.
vcEnetmoduleIncompatible
The module is incompatible, for example, a configured Enet module
is replaced with an FC module.
vcEnetmoduleHwDegraded
The module is being reported as degraded by the OA.
vcEnetmoduleUnknown
The condition of the module is unknown.
vcFcmoduleOk
The FC module is functioning normally.
vcFcmoduleEnclosureDown
The FC module is unable to communicate with the enclosure/OA.
vcFcmoduleModuleMissing
A configured module has been removed.
vcFcmoduleHwDegraded
The module is reporting a degraded hardware condition.
vcFcmoduleIncompatible
The module is incompatible, such as replacing a configured FC
module with an Enet module.
vcFcmoduleUnknown
The condition of the module is unknown.
vcPhysicalServerManagedStatusChanged
The following is an example of a physical server Cause string:
Server enc0:dev1 unable to communicate with enclosure enc0
The following is an example of a physical server RootCause string:
Server enc0:dev2 profile pending
The physical server managed status ReasonCodes are provided in the following table.
Physical server reason code Description
vcPhysicalServerOk
The server is functioning normally.
vcPhysicalServerEnclosureDown
The server is unable to communicate with the enclosure/OA.
vcPhysicalServerFailed
The server is in a failed condition.
vcPhysicalServerDegraded
The server is in a degraded condition.
vcPhysicalServerUnknown
The condition of the server is unknown.
vcFcFabricManagedStatusChanged
The following is an example of a FC fabric Cause string:
1 of 2 uplink ports are abnormal on BackupSAN fabric
