Virtual Connect domains 49
• The event severity is Info (informational).
• The event message is VCM user logout : Administrator@16.85.18.209.
The following table describes the Virtual Connect managed objects that are capable of generating System
Log events, along with the corresponding event ID ranges.
VC object name Object short name Event ranges
Domain
VCD 1000 – 1999
Enclosure
ENC 2000 – 2999
Ethernet Modules
ENET 3000 – 3999
FC Modules
FC 4000 – 4999
Servers
SVR 5000 – 5999
Profiles
PRO 6000 – 6999
Ethernet Network
NET 7000 – 7999
FC Fabric
FAB 8000 – 8999
Unknown Module
UNK
9000 – 9999
Network Access Groups
NAG 12000 – 12999
The event severity reflects the functional state of the Virtual Connect object. The event severities include:
• SEVERITY_INFO–A low-level condition for out-of-service equipment, system login/logout, and other
non-service affecting information
• SEVERITY_WARNING–A threshold was reached or an error condition is imminent
• SEVERITY_MINOR–An error condition that has no service impact
• SEVERITY_MAJOR–A critical event that impairs service and requires immediate action (substantially
diminished capacity or a service outage)
• SEVERITY_CRITICAL–A critical event that severely impairs service and requires immediate action
(substantially diminished capacity or a service outage)
