Virtual Connect networks 95
Task Action
Accept selected ports and return
to the Port Monitoring screen
Click OK.
Clear newly selected ports
without saving and return to the
Port Monitoring screen
Click Cancel.
Reset the filter criteria to include
all items in each filter
Click Reset Filters.
Ethernet Settings (Advanced Settings) screen
Use this screen to perform the following tasks:
• Set Server VLAN Tagging Support (on page 96).
• Set VLAN Capacity (on page 97).
• Use the Multiple Networks Link Speed Settings (on page 97) to set a custom value for preferred link
connection speed or maximum link connection speed.
• Enable or disable MAC Cache Failover (on page 98).
• Modify the refresh interval for MAC Cache Failover (on page 98).
• Enable or disable Network Loop Protection (on page 98) for all VC-Enet modules in the domain.
• Reset Network Loop Protection for all server ports in a loop-detected error state.
• Enable or disable Pause Flood Protection (on page 99) for all VC-Enet modules in the domain.
• Reset Pause Flood Protection for all server ports in a pause flood protected error state.
• Enable and configure Throughput Statistics ("Configuring Throughput Statistics" on page 100) for all
ports of each VC-Enet module, including Flex-10 subports.
• Configure domain wide LACP timer ("LACP timer configuration" on page 101).
