Converged networks with Fibre Channel over Ethernet and Data Center Bridging
Table Of Contents
17
Figure 10. DCBX dynamic negotiation
CNA willingness
CNA new parameters
XX
DCB - CDCB - C
Switch recommended
Migrating to converged fabrics
In a one-hop architecture, converged traffic goes from a server to a switch that splits it to Ethernet and Fibre
Channel. In two-hop architecture, converged traffic goes to a second switch before the split. The more
switch hops in a DCB-enabled network, the more difficult it is to keep the network operating at peak
efficiency while minimizing congestion. Figure 11 shows the expected industry path to convergence.
Figure 11. Industry path to convergence
