Field name Description
System Contact
Specify a contact name for this system when SNMP is enabled. The maximum
length is 20 characters.
Read Community
Controls SNMP read access when SNMP is enabled. The default value is "public".
The read community string must always be set when SNMP is enabled. The
maximum length is 24 characters.
SNMP Access
Table of networks that are allowed SNMP access
IP Address
IPv4 address for the allowed network
Network Mask Bits
Network mask bits for the allowed network
Type
Type of network
Action
Perform add and delete actions
SNMP Trap Destinations
SNMP trap destination table
Destination
User-designated name for the trap destination. The Destination name must be
unique.
IP Address
IPv4 address for the trap destination. DNS name is not supported.
Community String
The Community String acts like a password for a given trap destination. The
trap-receiving application can use the community string to filter the incoming traps.
Default: public
Format
Format of the new trap (SNMPv1)
Action
Perform edit and delete operations
The following table describes the available actions in the SNMP Configuration screen. Clicking another link
in the pull-down menu or left navigation tree causes current edits that have not been applied to be lost.
Task Action
Add SNMP access ("Adding
SNMP access" on page 44)
Click Add below the SNMP Access table, or right-click on the header row
of the SNMP Access table, and then select Add.
Delete SNMP access
Click Delete in the Action column, or right-click on the SNMP Access row,
and then select Delete.
Add an SNMP trap destination
("Adding an SNMP trap
destination" on page 43)
Click Add below the destination table, or right-click on the header row of
the destination table, and then select Add Destination.
Edit an SNMP trap destination
Click Edit in the Action column, or right-click on the trap destination row,
and then select Edit Destination.
Delete an SNMP trap destination
Click Delete in the Action column, or right-click on the trap destination
row, and then select Delete Destination.
Save changes
Click Apply.
SMI-S overview
The SMI-S was created by SNIA to standardize storage management solutions. SMI-S replaces multiple
disparate managed object models, protocols, and transports with a single object-oriented model for each
type of component in a storage network. SMI-S enables management applications (such as HP SIM) to
support storage devices from multiple vendors quickly and reliably because they are no longer proprietary.
SMI-S detects and manages storage elements by type, not by vendor.
You must have storage or domain user role permissions to configure SMI-S capabilities.
The ability to enable or disable SMI-S is not available on the HP VC 8Gb 24-Port FC module.
