KAIC15001-E error message in the GUI
If the GUI displays the KAIC15001-E error message, startup of Device Manager might not have
completed successfully. The following might be the cause:
• Ports required to start Device Manager are used by other processes.
Verify the ports described in the Port settings of the HP XP P9000 Command View Advanced Edition
Suite Software Administrator Guide are not being used by other processes.
Using Device Manager to manage a virtual machine
When Device Manager manages a virtual machine, the characters of the machine name in the following
appear as encoded characters:
• In the GUI:
The value of VMname displayed in a virtual machine name subwindow
• In the CLI:
The name attribute values for VM instances that are collected by executing the GetHost command.
The following characters might appear as encoded characters.
Displayed characterCharacter#
%25%1
%2f/2
%5c\3
Adding a host that has multiple IP addresses by Host Data Collector
When adding a host with multiple IP addresses to the Device Manager server, the first IP address
registered in the Device Manager server is added to the host. At this time, error messages are displayed
for IP addresses other than the first one. Ignore the error messages.
Registering and refreshing hosts
The KAIC169001-E message might appear when communications between Host Data Collector and
target multiple hosts are not successful in registering or refreshing hosts.
If this occurs, close the browser and then log in again five minutes later.
When HiRDB is installed in the system
During Common Component installation, HiRDB will be installed as the database management system.
However, as a result, Command View Advanced Edition Suite products will not be able to operate
together with the following list of HiRDB products. If any of these HiRDB products has been installed
on a computer, do not install Command View Advanced Edition Suite products on that computer.
Similarly, do not install any of these HiRDB products on a computer with Command View Advanced
Edition Suite products installed.
• HiRDB/Single Server
• HiRDB/Parallel Server
• HiRDB/Workgroup Server
• HiRDB/Run Time
• HiRDB/Developer's Kit
• HiRDB/SQL Executer
Important considerations 39
