8. From the executing node, execute the following command to migrate the database to the shared
disk.
installation-folder-of-Common-Component\bin\hcmdsdbclustersetup /
createcluster /databasepath target-folder-for-re-creating-database /
exportpath target-folder-for-storing-data /auto
createcluster
This option changes the P9000 Command View AE Suite product in a non-cluster configuration
to a cluster configuration.
databasepath
Specify the folder in which you want to re-create the database. Use an absolute path to a
folder on a shared disk. The path name must not exceed 63 bytes.
The characters that can be used to specify the path are shown below. Additionally, back-
slashes (\), colons (:), or forward slashes (/) can be used as path delimiters.
A to Z a to z 0 to 9 . _
exportpath
Specify the folder in which you want to store backup data. Use an absolute path to a folder
on a local disk. The path name must not exceed 85 bytes. The characters that can be used
to specify the path are the same as for databasepath.
auto
This option automatically changes the P9000 Command View AE Suite product services and
the HiRDB service to statuses appropriate for changing the database settings. After the
command is completed, the P9000 Command View AE Suite product services and the HiRDB
service are stopped.
CAUTION:
• If you execute the hcmdsdbclustersetup command, the setting of the port number
used by HiRDB is changed back to the default (23032/tcp).
• If target-folder-for-storing-data already exists, empty or delete the folder.
• Do not disconnect the shared disk from the executing node until the hcmdsdbcluster-
setup command finishes successfully.
• If you restart the server after the hcmdsdbclustersetup command has finished ab-
normally, the node to which the shared disk connects might switch to the standby node.
9. On the standby node, execute the following command to set the database on the shared disk as
the database to be used.
installation-folder-of-Common-Component\bin\hcmdsdbclustersetup /
createcluster /databasepath target-folder-for-re-creating-database /
exportpath target-folder-for-storing-data /auto
For details about the options that can be specified for the hcmdsdbclustersetup command,
see step 9.
For databasepath, specify the same folder as the one being used by the executing node to
re-create the database.
10. On both the executing and standby nodes, execute the following command to verify that the
P9000 Command View AE Suite product services are stopped:
installation-folder-of-Common-Component\bin\hcmdssrv /status
Administrator Guide (Web Version) 189
