DescriptionPort number
Used internally for Common Component communication (receiving a termination
message from the Web server).
This port number can be changed.
23018/tcp
Used internally for Common Component communication (communication with
the Web server).
This port number can be changed.
23025/tcp
Used internally for Common Component communication (receiving a termination
message from the Web server).
This port number can be changed.
23026/tcp
Used internally for Common Component communication (single sign-on) if the
OS of the management server is Windows.
This port number can be changed.
23031/tcp
Used internally for Common Component communication (HiRDB).
This port number can be changed.
23032/tcp
Used internally as dynamic ports for Common Component communication (HiRDB)
when the management server OS is Windows XP, Windows Server 2003 R2,
or Linux.
You cannot change the settings by using P9000 Command View AE Suite
products. If products using these ports are installed on the same computer, change
the settings of those products. For other OSs, the standard dynamic ports of the
OS are used.
45001/tcp to 49000/tcp
#:
This port is also used when SSL is enabled. If you want to permit only SSL communication, set up
a firewall.
Related topics:
• Changing ports used by Common Component, page 78
• Registering firewall exceptions , page 81
Ports used by the Device Manager server
For the management server, ensure that the port numbers specified for use by the Device Manager
server are different from the port numbers used by other programs installed on the same computer.
Table 13 Ports used by the Device Manager server
DescriptionPort number
Used for receiving SNMP traps from P9500, XP24000/XP20000,
XP12000/XP10000/SVS200, and XP1024/XP128.
You cannot change the settings by using Device Manager. If products using these
ports are installed on the same computer, change the settings of those products.
162/udp
Network configuration72
