Port numbers that must be registered as firewall exceptions
In an environment with firewalls set up in the network that connects the management server,
management clients, and storage systems, you need to register ports used by P9000 Command View
AE Suite products as firewall exceptions.
Table 19 Port numbers that must be registered as firewall exceptions between the management server
and management clients
Remarks
DestinationOriginator
MachinePort numberMachinePort number
This setting is required when
non-SSL communication is used.
Management server
2001/tcp
#
Management client
(GUI or Device
Manager CLI)
any/tcp
This setting is required when
SSL communication is used.
Management server
2443/tcp
#
Management client
(GUI or Device
Manager CLI)
any/tcp
This setting is required when
non-SSL communication is used.
Management server
20352/tcp
#
Management client
(Tiered Storage
Manager CLI)
any/tcp
This setting is required when
non-SSL communication is used.
Management server
23015/tcp
#
Management client
(GUI)
any/tcp
This setting is required when
SSL communication is used.
Management server
23016/tcp
#
Management client
(GUI)
any/tcp
This setting is required when
SSL communication is used.
Management server
24500/tcp
#
Management client
(Tiered Storage
Manager CLI)
any/tcp
#:
This port number can be changed.
Table 20 Port numbers that must be registered as firewall exceptions between the management server
and storage systems
Remarks
DestinationOriginator
MachinePort numberMachinePort number
-Management server162/udp
• P9500
• XP24000
• XP20000
• XP12000
• XP10000
• SVS200
• XP1024
• XP128
any/udp
