Remarks
DestinationOriginator
MachinePort numberMachinePort number
This setting is required when
non-SSL communication is used.
SMI-S provider
5988/tcp
#
Management serverany/tcp
This setting is required when
SSL communication is used.
SMI-S provider
5989/tcp
#
Management serverany/tcp
Legend:
-: Not applicable
#:
This port number can be changed.
Table 29 Port numbers that must be registered as firewall exceptions between the management server
and a CIM client
Remarks
DestinationOriginator
MachinePort numberMachinePort number
-Management server427/tcpCIM clientany/tcp
This setting is required when
non-SSL communication is used.
Management server
5988/tcp
#
CIM clientany/tcp
This setting is required when
SSL communication is used.
Management server
5989/tcp
#
CIM clientany/tcp
Legend:
-: Not applicable
#:
This port number can be changed.
Table 30 Port numbers that must be registered as firewall exceptions between the management server
and a mail server
Remarks
DestinationOriginator
MachinePort numberMachinePort number
This setting is required to send
an email to a user when the
following events occur:
• An alert occurs in a storage
system.
• A task executed from the
Migrate Data wizard com-
pletes.
Mail server
#2
25/tcp
#1
Management server
(Device Manager
server)
any/tcp
