DescriptionField
• SS
• Auto LUN
Shows license information used by BC, and the total license capacity reserved for
BC. Unlimited is shown when there is no limit on license capacity for BC.
Used Capacity (TB)
Shows license information used by SS, and the total license capacity reserved for
SS. Unlimited is shown when there is no limit on license capacity for SS.
XP Snapshot Used Capacity (TB)
Reviewing a pair’s operation history
You can review the operations that have been performed on a pair using the History window.
1. In RWC, click Actions > Local Replications > BC/SS > History.
If some of the pairs include LUSE volumes, or if the total number of the following pairs and
migration plans is 500 or more in the storage system, you may need to wait for a while until
the History window shows operation history.
The History window show the following pair types:
• BC
• FS
• SS
• Auto LUN migration plans
2. Locate the BC History list in the upper area.
3. To change the order in which items are listed, click a column title in the list.
The list is sorted based on the items in the clicked column.
• If there are more than 16,384 records of operations, the list is divided into multiple pages
and only the list which is currently shown is sorted.
• If you click the same column title again, you can switch the sorting order (Ascending or
Descending).
130 Monitoring and maintaining the system (secondary window)
