F Business Copy GUI reference (secondary window)
This appendix describes the BC windows and dialog boxes in the previous version of the RWC
GUI, which opens in a secondary window.
Pair Operation window
Use this window to view BC pairs.
You can perform the following procedures from the window:
• “Creating L1 and/or L2 pairs” (page 115)
• “Splitting pairs, creating and splitting pairs” (page 117)
• “Suspending pair creation” (page 120)
• “Resynchronizing pairs” (page 121)
• “Deleting pairs” (page 123)
• “Monitoring pair activity, status (secondary window)” (page 125)
Select one of the following areas of the Pair Operations window for information:
NOTE: The Pair Operation window opens and shows information for BC and SS pairs. This topic
explains the items related to the BC pairs. For more information about the items related to the SS
pairs, see the HP XP P9000 Snapshot User Guide.
Main components
DescriptionField
The connected port and host group. Select the desired port or host group to display related
LUs.
Tree
If you select storage system on the top of the tree, a volume is not shown.
The pair information. For more information, see “Volume list” (page 134).Volume list
Pair Operation window 133
