Display Filter dialog box
Use this dialog box to filter the volumes on the Pair Operations window. To open this dialog box,
click Display Filter in the Pair Operation window.
The filter settings you select are effective in the current session only. They reset when you select
another software product.
DescriptionField
The cache logical partition (CLPR)CLPR
The internal or external volumes are specified. Both boxes are selected by default. Clear
the box you do not want.
Volume Type
Attribute
• Volume Attribute. If you select the Reserved check box, only reserved volumes display.
Reserved volumes include volumes specified as S-VOLs.
• Pair Attribute. You can select pair volumes, non-pair volumes, or cascade levels (L1 or
L2).
The status of the pairs you want to see.Pair Status
NOTE: If you select Cascade, you cannot select Reserved. If you select L1-L2, you cannot select
any other check boxes.
If you do not select Business Copy or Snapshot, all the check boxes in each tab are unavailable.
History window
Use this window to view the history of operations performed on BC, FS, and SS pairs and data
associated with the operations.
• The upper pane shows BC history.
• The lower pane shows FS and SS history.
History window 137
