DescriptionItem
Status, continued
• This icon is used for the following:
The pair is split. Status names are:
BC: PSUS
BC Z: Split/SUSPOP
The pair is being split in Quick Split mode. Status names are:
BC: PSUS(SP)PSUS
BC Z: V-Split/SUSPVS
The pool is full. Status name is:
FS, SS: PFUS
•
The pair is suspended. Status names are:
BC: PSUE
BC Z: Supend/SUSPER
For more information, see “Pair status definitions” (page 53).
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier.
• LDEV Name: The S-VOL’s LDEV name.
• Port ID: The port name of the P-VOL LDEV’s LUN path.
For BC Z, a hyphen (-) is shown.
• Host Group Name: The host group name of the P-VOL LDEV’s LUN path.
For BC Z, a hyphen (-) is shown.
• LUN ID: The LUN ID of the S-VOL LDEV's LUN path.
For BC Z, a hyphen (-) is shown.
• Emulation Type: The S-VOL’s emulation type.
• Capacity: The S-VOL’s capacity.
• CLPR: The S-VOL’s CLPR number.
(FS and SS only.)Snapshot Date
The date and time that a snapshot was acquired.
If you have not set a snapshot date for FS pairs, this item is blank.
For BC and BC Z, a hyphen (-) is shown.
(FS and SS only.)Pool Name (ID)
The pool name and identification number.
If you have not set a pool name for FS pairs, this item is blank.
For BC and BC Z, a hyphen (-) is shown.
(BC and BC Z only.)Copy Pace
The speed at which the split operation is performed.
Values: Faster, Medium, Slower
If you have not set a copy pace for FS pairs, this item is blank.
For FS and SS pairs, a hyphen (-) is shown.
The consistency Group IDCTG ID
The mirror unit numberMirror Unit
The LDEV’s topology identifierTopology ID
Click to open the Create Pairs wizard.Create Pairs button
Local Replications window 79
