DescriptionItem
Click to open the Split Pairs window.Split Pairs button
Click to open the Resync Pairs window.Resync Pairs button
Opens the View Pair Synchronous Rate window.View Pair Synchronous Rate*
Opens the View Pair Properties window.View Pair Properties*
Opens the Suspend Pairs window.Suspend Pairs*
Opens the Delete Pairs window.Delete Pairs*
Opens the dialog box for downloading table information to a file.Export*
*An option you can choose from the More Actions menu.
Reserve Volumes tab
Use this tab on the Local Replications window to view reserved volume information for local
replication, and to perform the following operations:
• “Reserving secondary volumes” (page 37)
• “Removing reserve attribute from a volume” (page 59)
DescriptionItem
The reserved volume LDEV’s identifierLDEV ID
The reserved volume LDEV’s nameLDEV Name
The reserved volume’s capacityCapacity
The number of paths to reserved volume.Number of Paths
Click to open the Add Reserve Volumes window.Add Reserve Volumes button
Click to open the Remove Reserve Volumes window.Remove Reserve Volumes button
Click to open the dialog box for downloading table information to a file.Export button
Consistency Group tab
Use this tab in the Local Replications window to view consistency group information for local
replication
80 Business Copy GUI reference
