DescriptionItem
The consistency group identifier. Click to open the Consistency Group Properties
window.
CTG ID
Possible values include:Status
• BC Used: Consistency group used by BC.
• BC Z Used (RAID Manager): Consistency group used for BC Z pairs and
managed with RAID Manager.
• BC Z Used (PPRC/BCM): Consistency group used for BC Z pairs and managed
using PPRC or BCM.
• FS Used: Consistency group used by FS pairs.
• SS Used: Consistency group used for SS pairs.
• Mainframe Reserved: Consistency group reserved for PPRC or BCM.
• Free: Consistency group not being used and is not reserved.
• (Changing...): Status is in the process of changing.
The number of pairs for the consistency group in use.Number of Pairs
Click to open the Reserved Mainframe CTGs window.Reserve Mainframe CTGs button
Click to open the Release Reserved Mainframe CTGs window.Release Reserved Mainframe CTGs
button
Click to open the dialog box for downloading table information to a file.Export button
View Pair Properties window
Use this window to review pair and volume details for local replication.
For detailed information, see “Monitoring pair, volume details” (page 57).
View Pair Properties window 81
