Histories table
DescriptionItem
The operation date and timeDate
Primary Volume (Source Volume for
FC Z/FCSE)
• LDEV ID: The P-VOL/source volume’s LDEV identifier
• Provisioning Type: The provisioning type.
Values:
- Basic: Internal volume
- THP: THP V-VOL
- External: External volume
- External MF: Migration volume
Secondary Volume (Target Volume
for FC Z/FCSE)
• LDEV ID: The secondary/target volume’s LDEV identifier.
• Provisioning Type: The provisioning type.
Values:
- Basic: Internal volume
- THP: THP V-VOL
- External: External volume
The mirror unit number.Mirror Unit
Shown only when FS or SS is the selected Copy Type.
The pool identifier.Pool ID
Shown only when FS or SS is the selected Copy Type.
The relationship identifier.Relationship ID
Shown only when FC Z/FCSE is the selected Copy Type.
The code for the type of operation performed.Description Code
The description of the operation.Description
Click to open the dialog box for downloading table information to a file.Export
Consistency Group Properties window
Use this window to view a list of consistency groups, with status and number of pair information;
also use it to view a consistency group’s properties.
For full information, see “Monitoring consistency groups” (page 57).
