Pairs table
This table shows pairs for P-VOL and/or S-VOL to which you are allocated.
DescriptionItem
Primary Volume
• LDEV ID: The P-VOL’s LDEV identifier.
• LDEV Name: The P-VOL’s LDEV name.
• Emulation Type: The P-VOL’s emulation type.
• Capacity: The P-VOL’s volume capacity.
• CLPR: The P-VOL’s CLPR number.
Shows the following types of pairs:Copy Type
• BC-L1: BC L1
• BC-L2: BC L2
• FS: FS
• SS: SS
• BC Z: BC Z
(FS only.)Snapshot Group
The snapshot group name.
If you have not set a snapshot group for FS pairs, this item is blank.
For BC, BC Z and SS pairs, a hyphen (-) is shown.
The pair status.Status
For more information, see “Pair status definitions” (page 53).
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier.
• LDEV Name: The S-VOL’s LDEV name.
• Emulation Type: The S-VOL’s emulation type.
• Capacity: The S-VOL’s volume capacity.
• CLPR: The S-VOL’s CLPR number.
(FS and SS only.)Snapshot Date
The date and time that a snapshot was acquired.
For BC and BC Z pairs, a hyphen (-) is shown.
(FS and SS only.)Pool Name (ID)
The pool name and identification number.
For BC and BC Z pairs, a hyphen (-) is shown.
(BC and BC Z only.)Copy Pace
The speed at which the split operation is performed.
Values: Faster, Medium, Slower
For FS and SS pairs, a hyphen (-) is shown.
The mirror unit number.Mirror Unit
Click to open the Pair Properties window.Detail button
Create Pairs wizard
Use this wizard to create pairs, including specifying new pair details.
