Select Primary Volumes window
Use this window to select LDEVs that are P-VOLs.
DescriptionItem
(FS and SS only.)Use Primary Volumes of BC/SS Pairs
Indicates whether the P-VOLs are used.
• Yes: Only FS and SS P-VOL LDEVs are shown in the Available LDEVs table.
• No: Only unpaired LDEVs are shown in the Available LDEVs table.
(BC/SS, FS, SS only.)Port ID
Filters LDEVs in the Available LDEVs table according to the port ID.
(BC/SS, FS, SS only.)Host Group Name
Filters LDEVs in the Available LDEVs table according to host group name. Any
is the default.
Available LDEVs table
DescriptionItem
The LDEV’s identifier.LDEV ID
The LDEV’s name.LDEV Name
(BC/SS, FS, SS only.)Port ID
The port name of the LDEV’s LUN path.
(BC/SS, FS, SS only.)Host Group Name
The host group name of the LDEV’s LUN path.
(BC/SS, FS, SS only.)LUN ID
The LUN ID of the LDEV's LUN path.
The LDEV’s provisioning type.Provisioning Type
Values:
• Basic: Internal volume
• DP: THP volume
• External: External volume
The LDEV’s emulation type.Emulation Type
90 Business Copy GUI reference
