DescriptionItem
Capacity of the LDEVCapacity
CLPR number of the LDEVCLPR
The number of S-VOLs.Number of Secondary Volumes
(BC only) The number for an L1 pair does not include the number of L2 S-VOL.
(FS and SS only.)Primary Volumes
Information about the P-VOL when the LDEV is used as a S-VOL for an existing
pair.
Values:
• LDEV ID: The LDEV identifier.
• LDEV Name: The LDEV name.
• Port ID: The port name of the LDEV’s LUN path.
• Host Group Name: The host group name of the LDEV’s LUN path.
• LUN ID: The LUN ID of the LDEV's LUN path.
• Emulation Type: The volume’s emulation type.
• Capacity: The volume’s capacity.
• CLPR: The volume’s CLPR number.
(FS and SS only.)Mirror Unit
The mirror unit number.
(FS and SS only.)Pool Name (ID)
The pool name and ID.
For BC and BC Z, this item is blank.
(FS and SS only.)Select Pool button
Click to open the Select Pool window.
Note: If you selected Yes for Use Primary Volumes of Snapshot Pairs, this button
is not available.
Selected LDEVs table
DescriptionItem
The selected P-VOL’s LDEV identifier.LDEV ID
The selected P-VOL’s LDEV name.LDEV Name
(BC/SS, FS, and SS only.)Port ID
The port name of the LDEV’s LUN path.
(BC/SS, FS, and SS only.)Host Group Name
The host group name of the LDEV’s LUN path.
(BC/SS, FS, and SS only.)LUN ID
The LUN ID of the LDEV's LUN path.
The LDEV’s provisioning type.Provisioning Type
Values:
• Basic: Internal volume
• DP: THP volume
• External: External volume
Create Pairs wizard 91
