DescriptionItem
Choose to create a new snapshot group or use an existing snapshot group.
• Create new snapshot group: The new snapshot group name is entered.
• Use defined snapshot group: An existing snapshot group is selected.
If you have not set a snapshot group for FS pairs, this item is blank.
(BC/SS and BC Z only.)Change Options button
Click to open the Change Options dialog box, from which you can change the
Split Type and Copy Pace.
Click to remove the pair from the table.Remove button
(BC only) You cannot remove L1 pairs if they have an L2 pair.
Available LDEVs table
DescriptionItem
The LDEV’s identifier.LDEV ID
The LDEV’s name.LDEV Name
(BC/SS only.)Port ID
The port name of the LDEV’s LUN path.
(BC/SS only.)Host Group Name
The host group name of the LDEV’s LUN path.
(BC/SS only.)LUN ID
The LUN ID of the LDEV's LUN path.
The LDEV’s emulation type.Emulation Type
The LDEV’s capacity.Capacity
Provisioning type of the LDEV:Provisioning Type
• Basic: Internal volume
• THP: THP V-VOL
• External: External volume
• Snapshot: FS or SS volume
LDEV’s CLPR numberCLPR
(BC/SS only.)Number of Secondary Volumes
The number of S-VOL that the selected P-VOL has been assigned so far. This may
include the number of S-VOL for an L2 pair that is already created.
(BC/SS and BC Z only.)Reserve Volume
Indicates whether LDEV is reserved as an S-VOL.
Values: Yes or No
Selected Pairs table
DescriptionItem
Information about the P-VOL.Primary Volume
• LDEV ID: The P-VOL’s LDEV identifier.
• LDEV Name: The P-VOL’s LDEV name.
