DescriptionItem
For FS and SS pairs, a hyphen (-) is shown.
(FS and SS only.)Pool Name (ID)
The pool name and ID number.
For BC/SS and BC Z pairs, a hyphen (-) is shown.
Confirm window
Selected Pairs table
DescriptionItem
Primary Volume
• LDEV ID: The P-VOL’s LDEV identifier.
• LDEV Name: The P-VOL’s LDEV name.
• Port ID: The port name of the P-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• Host Group Name: The host group name of the P-VOL LDEV’s LUN path.
For BC Z, this item is blank.
• LUN ID: The LUN ID of the P-VOL LDEV's LUN path.
For BC Z, this item is blank.
• Emulation Type: The P-VOL’s emulation type.
• Capacity: The P-VOL’s volume capacity.
• CLPR: The P-VOL’s CLPR number.
Shows the following types of pairs:Copy Type
• BC-L1: BC L1
• BC-L2: BC L2
• FS: FS
• SS: SS
• BC Z: BC Z
(FS only.)Snapshot Group
The snapshot group name.
If you have not set a snapshot group for FS pairs, this item is blank.
96 Business Copy GUI reference
