DescriptionItem
(FS only.)New Snapshot Group
• Yes: New snapshot group is used.
• No: Existing snapshot group is used.
Secondary Volume
• LDEV ID: The S-VOL’s LDEV identifier.
• LDEV Name: The S-VOL’s LDEV name.
• Port ID: (FS and BC/SS only.) The port name of the S-VOL LDEV’s LUN path.
• Host Group Name: (FS and BC/SS only.) The Host group name of the S-VOL
LDEV’s LUN path.
• LUN ID: (FS and BC/SS only.) The LUN ID of the S-VOL LDEV's LUN path.
• Emulation Type: The S-VOL’s emulation type.
• Capacity: The S-VOL’s volume capacity.
• CLPR: The S-VOL’s CLPR number.
(BC/SS and BC Z only.)Split Type
• Non Split: Does not split the pair.
• Quick Split: Splits the pair immediately
• Steady Split: Splits the pair after all differential data is copied
(BC/SS and BC Z only.)Copy Pace
The speed at which the split operation is performed.
Values: Faster, Medium, Slower
(FS and SS only.)Pool Name (ID)
The pool name and ID number.
(BC/SS and BC Z only.)Mirror Unit
The mirror unit number.
Split Pairs wizard
Use this wizard to split pairs.
Split Pairs window
Use this window to split pairs.
For full information, see “Splitting pairs” (page 47).
Split Pairs wizard 97
