QuickSpecs

HP Z Turbo Drive G2

Overview

c04604048 — DA-15238 Worldwide — Version 1 — April 5, 2015

Page 1

HP Z Turbo Drive

Introduction

Storage technology with NAND media is outgrowing the bandwidth limitations of the SATA bus. New high performance storage

solutions will connect directly to the PCIe bus for revolutionary performance improvements. These components will be available in

a variety of form factors and performance levels, designed specifically for certain market segments, and ultimately the costs will

continue to decline as the technology evolves.

Performance

HP Z Turbo Drive G2

The new HP Z Turbo Drive G2 features the next generation PCIe SSD. This M.2 form factor device uses PCIe Gen3 x4 which enables

performance levels greater than 2GB/s. The Random Read performance is significantly improved also, due to the NVMe controller

technology used on the device. This performance is available at a price that is comparable to commercial SATA SSDs.

The HP Z Turbo Drive G2 will be supported on desktop platforms of HP Z Workstations. It will support storage configurations as a

Boot device and as a Data device. It also can be configured with other storage components including SATA and SAS drives and

controllers. Not all configurations are available from the factory.

Summary of content (6 pages)

PAGE 1
QuickSpecs HP Z Turbo Drive G2 Overview HP Z Turbo Drive Introduction Storage technology with NAND media is outgrowing the bandwidth limitations of the SATA bus. New high performance storage solutions will connect directly to the PCIe bus for revolutionary performance improvements. These components will be available in a variety of form factors and performance levels, designed specifically for certain market segments, and ultimately the costs will continue to decline as the technology evolves.
PAGE 2
QuickSpecs HP Z Turbo Drive G2 Overview HP Z Turbo Drive G2 256GB PCIe SSD Capacity: 256GB SSD NAND Type: MLC Read Bandwidth (128KB): 2150 MB/s Write Bandwidth (1MB): 1260 MB/s Random Read IOPS (4KB): 300K Random Write IOPS (4KB): 100K Endurance (Total Bytes Written): 146 TB Weight: 3.
PAGE 3
QuickSpecs HP Z Turbo Drive G2 Overview Microsoft Windows 7, Microsoft Windows 8 Other OS may be supported by the card for use in other systems. Support for OPAL hardware encryption: No Support for Secure Erase: Yes Supported in HP Performance Advisor: yes (includes wear gauge) Approved PCIe slots : Recommended slot order for: Recommended slot order for Z840 1. Slot 1 2. Slot 6 3. Slot 3 (Requires 2nd CPU) 4.
PAGE 4
QuickSpecs HP Z Turbo Drive G2 Technical Specifications Storage / Hard Drives HP Z Turbo Drive G2 256GB PCIe SSD Capacity Interface Operating Temperature 256GB PCI Express 3.0 x4 electrical x4 physical 32° to 158° F (0° to 70° C) HP Z Turbo Drive G2 512GB PCIe SSD Capacity Interface Operating Temperature 512GB PCI Express 3.
PAGE 5
QuickSpecs HP Z Turbo Drive G2 Summary of Changes Date of change: Version History: Description of change: c04604048 — DA-15238 Worldwide — Version 1 — April 5, 2015 Page 5
PAGE 6
QuickSpecs HP Z Turbo Drive G2 © Copyright 2015 Hewlett-Packard Development Company, L.P. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. The information contained herein is subject to change without notice.
