7 External cards and devices
Using memory card readers (select models only)
Optional memory cards provide secure data storage and convenient data sharing. These cards are often used
with digital media–equipped cameras and PDAs as well as with other computers.
Inserting a memory card
CAUTION: To reduce the risk of damage to the memory card connectors, use minimal force to insert a
memory card.
1. Hold the card label-side up, with the connectors facing the computer.
2. Insert the card into the memory card reader, and then press in on the card until it is firmly seated.
You will hear a sound when the device has been detected, and a menu of options may be displayed.
Removing a memory card
CAUTION: To reduce the risk of loss of data or an unresponsive system, use the following procedure to
safely remove the memory card.
1. Save your information and close all programs associated with the memory card.
2. Click the remove hardware icon on the Windows desktop in the notification area, at the far right of the
taskbar. Then follow the on-screen instructions.
Using memory card readers (select models only) 51
