User Guide - Windows 7
Table Of Contents
- Welcome
- Getting to know your computer
- Connecting to a network
- Connecting to a wireless network
- Connecting to a wired network
- Navigating using the keyboard, touch gestures and pointing devices
- Multimedia
- Power management
- Shutting down the computer
- Setting power options
- Using power-saving states
- Using battery power
- Finding additional battery information
- Using Battery Check
- Displaying the remaining battery charge
- Maximizing battery discharge time
- Managing low battery levels
- Inserting or removing the battery
- Conserving battery power
- Storing a user-replaceable battery (select models only)
- Disposing of a user-replaceable battery (select models only)
- Replacing a user-replaceable battery (select models only)
- Using external AC power
- Switchable graphics/dual graphics (select models only)
- External cards and devices
- Drives
- Security
- Protecting the computer
- Using passwords
- Using antivirus software
- Using firewall software
- Installing critical security updates
- Using HP Client Security (select models only)
- Installing an optional security cable
- Using the fingerprint reader (select models only)
- Maintenance
- Backup and recovery
- Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI)
- Using HP Sure Start
- Support
- Specifications
- Traveling with or shipping your computer
- Troubleshooting
- Troubleshooting resources
- Resolving issues
- The computer is unable to start up
- The computer screen is blank
- Software is functioning abnormally
- The computer is on but not responding
- The computer is unusually warm
- An external device is not working
- The wireless network connection is not working
- A disc does not play
- A movie is not visible on an external display
- The process of burning a disc does not begin, or it stops before completion
- Electrostatic discharge
- Index
1. Select Start > All Programs > Intel > Intel Rapid Storage Technology.
2. Click the Acceleration link, and then click the Disable Acceleration link.
3. Wait for the Acceleration Mode to complete.
4. Click the Reset to Available link.
IMPORTANT: You must temporarily disable SRT when changing RAID modes. Make the change and then re-
enable SRT. Failure to temporarily disable this feature will prevent you from creating or changing RAID
volumes.
NOTE: HP does not support SRT with self-encrypting drives (SEDs).
Removing or replacing the service door
Removing the service door
Remove the service door to access the memory module slot, hard drive, and other components.
1. Remove the battery (see Removing a battery on page 46).
2. With the battery bay toward you, slide the service door release latch (1) to the left, remove the screw (if
the optional screw is being used)
(2), and then slide the release latch again (3) to release the service
door.
NOTE: If you do not want to use the optional screw, you can store it inside the service door.
Using hard drives 57
