Components Description
(14)
Audio-out (headphone) jack/Audio-
in (microphone) jack
Connects optional powered stereo speakers, headphones, earbuds, a
headset, or a television audio cable. Also connects an optional headset
microphone. This jack does not support optional microphone-only
devices.
WARNING! To reduce the risk of personal injury, adjust the volume
before putting on headphones, earbuds, or a headset. For additional
safety information, refer to the Regulatory, Safety, and Environmental
Notices.
To access this guide:
1. Type support in the taskbar search box, and then select the HP
Support Assistant app.
‒ or –
Click the question mark icon in the taskbar.
2. Select My PC, select the Specifications tab, and then select User
Guides.
NOTE: When a device is connected to the jack, the computer speakers
are disabled.
(15) Battery light When AC power is connected:
●
White: The battery charge is greater than 90 percent.
●
Amber: The battery charge is from 0 to 90 percent.
●
Off: The battery is not charging.
When AC power is disconnected (battery not charging):
●
Blinking amber: The battery has reached a low battery level. When
the battery has reached a critical battery level, the battery light
begins blinking rapidly.
●
Off: The battery is not charging.
(16)
Power connector Connects an AC adapter.
(17) Smart card reader Supports optional smart cards.
6 Chapter 2 Components
