Specifications 11
Specifications
In this section
HP NC110T PCI Express Gigabit Server Adapter specifications .................................................................. 11
UTP cable specifications.......................................................................................................................... 12
HP NC110T PCI Express Gigabit Server Adapter
specifications
Specification Value
Network Controller Chipsets Intel® 82571GI
Bus Type x1 PCI Express v1.0a
Bus Width One lane
On-board Memory 48 KB
Data Transfer Method Bus Master DMA
Boot ROM Support Yes
Management Capabilities WOL, PXE 2.2, ACPI 1.1a
Power Requirement 670 mA @ 3.3 VDC max
Data Transmission Rate 10 Full/10 Half, 100 Full/100 Half, 1000 Full
Standards Supported IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x (flow control), IEEE
802.3ad (link aggregation), IEEE 802.1p (QoS), IEEE 802.1q (VLAN tagging)
Dimensions 12.95 cm x 6.86 cm [5.1 in x 2.7 in (L x W)] (without bracket)
Connector and Distances 10BASE-T: Category 3, 4, or 5 UTP 100 M (328 ft)
100BASE-TX: CAT5 UTP 100 M (328 ft)
1000BASE-TX: CAT5 UTP 100 M (328 ft)
Interrupts Supported Automatically configured
Temperature Range Operating: 0°C to 55°C (32°F to 131°F)
Storage: -40°C to 185°C (-40°F to 85°F)
Relative Humidity (non-
condensing)
Operating: 10% to 95%
Storage: -5% to 95%
Safety Compliance UL Mark (US and Canada)
CE Mark
EN60950
RoHS (European Union)
