Specifications 10
Specifications
In this section
HP NC340T PCI-X Quad-Port Gigabit Server Adapter specifications ............................................................ 10
UTP cable specifications.......................................................................................................................... 11
RJ-45 pinouts and crossover function ........................................................................................................ 11
HP NC340T PCI-X Quad-Port Gigabit Server
Adapter specifications
Specification Value
Network Controller Chipsets Intel® 82546GB Dual MAC/PHY
Bridge Chipset Pericom 2-Port PCI-X Bridge
Bus Type PCI-X or PCI
Bus Width 64 bits
Bus Speed 64-bit/133-MHz PCI-X bus-master
On-board Memory 256Kb
Data Transfer Method Bus Master DMA
Boot ROM Support Yes
Management Capabilities WOL (Port A only), PXE 2.2 (port A only), ACPI 1.0
Power Requirement 1850 mA@5V max
Data Transmission Rate 10 Full/10 Half, 100 Full/100 Half, 1000 Full
Standards Supported IEEE 802.3ab, 802.3u, 802.3
Dimensions 16.23 cm x 10.66 cm (without bracket) [6.40 x 4.2 in (L x W)]
Connector and Distances 10BASE-T: Category 3, 4, or 5 UTP 100 M (328 ft)
100BASE-TX: CAT5 UTP 100 M (328 ft)
1000BASE-TX: CAT5 UTP 100 M (328 ft)
Interrupts Supported Automatically configured
Temperature Range Operating: 0°C to 55°C (32°F to 131°F)
Storage: -30°C to 60°C (-22°F to 140°F)
Relative Humidity (non-
condensing)
Operating: 20% to 75%
Storage: 20% to 80%
Emissions Classifications Class B
