Specifications 11
Specification Value
Agency Approvals USA: FCC (CFR 47 part 15) and UL 60950
Canada: ICES-003 and CSA 60950
Japan: VCCI
Korea: MIC (RRL), EMC Registration
Australia: ACA, AS/NZS3548/EN55022:1998 (CISPR 22), EN55024:1998
European Union: EN 55022:1998 (CISPR 22), EN 55024:1998, and IEC
60950:1999 (EN 60950:2000)
Safety Compliance UL Mark (US and Canada)
CE Mark
EN 60590
UTP cable specifications
To connect to the network, the NC340T uses the following cable for 1000Base-T transmission:
• CAT5 UTP or better twisted-pair
• 22-26 AWG, 100Ω @ 1 MHz
• EIA/TIA 568a or EIA/TIA 568b
NOTE: For Gigabit over copper installations, CAT5 UTP or better 1000Base-T cable must
comply with the IEEE 802.3ab 1000Base-T standard. For new installations, CAT5e (enhanced
CAT5) or better cable is recommended. Maximum distances for Gigabit over copper cable are
100 meters (328 feet).
RJ-45 pinouts and crossover function
The Ethernet standard also specifies that each segment implement a crossover function to connect the
transmitter of one device to the receiver of a device at the other end, and vice-versa. The crossover
function may be implemented internally at the hub or switch or externally through the twisted-pair media.
10/100 pinouts using internal, straight-through crossover
If the crossover function is implemented internally, the port is labeled MDI-X (Medium Dependent Interface-
Crossover). When an MDI-X port is connected to an MDI port, the twisted pair media should be wired
straight-through using the physical pinouts indicated.
Pin Function Color match Function Pin
1 TD+ Orange TD+ 1
2 TD- Orange/White TD- 2
3 RD+ Green RD+ 3
4
Blue/White
4
5
Blue
5
6 RD- Green/White RD- 6
